PROEL TFLV-10 P
16.100 ден
Proel’ s TFLV/ TFL flying trapezoidal speaker series is a line of enclosures suitable for installation or touring use, available in hard epoxy texture finish with extremely rugged and anti-scratch coating, or in compact class 1 carpet. The cabinets, designed asymmetrically for wedge monitor applications, are made of 18 mm birch plywood, incorporate a thick metal grille, stand adapter and ergonomic carrying handles for easy transport. Commercial M10 threads/ eyebolts guarantee maximum enclosure suspension facility.
На залиха
PROEL TFLV-10 P
System type : 2-way vented enclosure
Nominal Impedance : 8 ohm
Input power rating (continuous) : 200 W
Input power rating (peak) : 400 W
Frequency response : 65Hz – 18kHz (-6dB, +6dB)
Sensitivity : 97dB @ 1W/1m
Maximum (peak) Output : 123 dB @ 1m
Low Frequency Device : 10” woofer – 2” voice coil
High Frequency Device : 1” throat – 1.4” voice coil
Coverage Angle H. (-6 dB) : 70??
Coverage Angle V. (-6 dB) : 70??
Trapezoidal taper : 10??
Monitor Taper : 40??
Crossover Frequency : 3000 Hz
Signal Processing : Proel DSO26 (biamp mode)
Flying System : 4 x M10 – top, bottom, rear
Connectors : 2 x SPK4MP linked
Construction : 18mm brich plywood
Finishing : Anti-scratch coating
Cabinet Colour : Black
Mounting Hole : 1 x bottom
Weight : 15 kg (33.075 lb)
Dimensions (W x H x D) : 35.5 x 52 x 31 cm
