PROEL TFLV-10 P

System type :  2-way vented enclosure
Nominal Impedance :  8 ohm
Input power rating (continuous) :  200 W
Input power rating (peak) :  400 W
Frequency response :  65Hz – 18kHz (-6dB, +6dB)
Sensitivity :  97dB @ 1W/1m
Maximum (peak) Output :  123 dB @ 1m
Low Frequency Device :  10” woofer – 2” voice coil
High Frequency Device :  1” throat – 1.4” voice coil
Coverage Angle H. (-6 dB) :  70¡Æ
Coverage Angle V. (-6 dB) :  70¡Æ
Trapezoidal taper :  10¡Æ
Monitor Taper :  40¡Æ
Crossover Frequency :  3000 Hz
Signal Processing :  Proel DSO26 (biamp mode)
Flying System :  4 x M10 – top, bottom, rear
Connectors :  2 x SPK4MP linked
Construction :  18mm brich plywood
Finishing :  Anti-scratch coating
Cabinet Colour :  Black
Mounting Hole :  1 x bottom
Weight :  15 kg (33.075 lb)
Dimensions (W x H x D) :  35.5 x 52 x 31 cm
